Raw Materials Processing --- granite, aggregate, rock, gold stone, gravel, basalt, slag, ore, etc.
Are you interested in our machines?
Stone crusher can be used to process over 120 kinds of stones in mining, quarry, etc. The crushed stones have wide market demand in many industries, such as construction, building, road, highway, water conservancy and other fields.
Crusher Types---We have small, medium and large stone crusher for sale, stationary & mobile types for choice, meeting your different needs.
The working principle of each type of stone crusher is different. Take the traditional jaw crusher as an example. When the jaw crusher is working, the motor drives the belt and pulley to move the movable jaw up and down through the eccentric shaft. When the movable jaw rises, the angle between the toggle plate and the movable jaw increases, thereby pushing the movable jaw plate to approach the fixed jaw plate, and at the same time, the material is crushed or split to achieve the purpose of crushing; when the movable jaw descends, the angle between the toggle plate and the movable jaw decreases, and the movable jaw plate leaves the fixed jaw plate under the action of the pull rod and spring. At this time, the crushed material is discharged from the lower opening of the crushing chamber. As the motor rotates continuously, the movable jaw of the crusher moves periodically to crush and discharge materials, realizing mass production.
Chat OnlineFocusing on crushing machinery for more than 40 years, Fote Machinery has provided professional project guidance, equipment production, production line construct, management and operation services for more than one million customers.
Cone crusher
HD German version jaw crusher
Hammer crusher
| Specification | Model | Diameter of large end of crushing cone (mm) |
Processing capacity (t/h) |
| Φ600 | PYB600 | 600 | 40 |
| PYD600 | 12-23 | ||
| Φ900 | PYB900 | 900 | 50-90 |
| PYZ900 | 20-65 | ||
| PYD900 | 15-50 | ||
| Φ1200 | PYB1200 | 1200 | 110-168 |
| PYZ1200 | 42-135 | ||
| PYD1200 | 18-105 | ||
| Φ1750 | PYB1750 | 1750 | 180-360 |
| PYZ1750 | 80-210 | ||
| PYD1750 | 60-180 | ||
| Φ2200 | PYB2200 | 2200 | 420-700 |
| PYZ2200 | 130-410 | ||
| PYD2200 | 80-200 |
| Model | Feeding opening size(mm) | Max.Feeding size（mm） | Capacity (t/h) |
| HD72(57) | 460×720 | 425 | 50-120 |
| HD86(69) | 580×860 | 500 | 60-280 |
| HD98(751) | 680×980 | 630 | 110-410 |
| HD110(912) | 850×1100 | 750 | 170-550 |
| HD125 | 950×1250 | 900 | 280-750 |
Note:processing Capacity May Vary With Different Materials And Feeding Sizes.
| Specification | Capacity(t/h) | Power (kw) |
| PC 400×300 | 3-10 | 4P 11 |
| PC 600×400 | 6-22 | 4P 22 |
| PC 800×600 | 10-40 | 4P 55 |
| PC 1000×800 | 15-50 | 4P 75 |
| PC 1000×1000 | 18-75 | 4P 90 |
| PC 1200×1200 | 22-95 | 4P 132 |
Note:processing Capacity May Vary With Different Materials And Feeding Sizes.
Our Crushing Equipment and Dryer Equipment has been exported to over 160 countries, such as, Pakistan, Egypt, Indonesia, Malaysia, Ethiopia, Nigeria, South Africa, etc. The following is how our crushing machines work at the customer site. Furthermore, we provide 100% factory price and maximum discount for you. Additionally, if you are new in this industry, we will provide professional suggestions and solutions for you.
Case1
Case2
Case3
Please feel free to write down your requirement in the form below. We will reply you within 24 hours and we will protect your personal privacy information.
