CI Series Impact Crusher

CI Series Impact Crusher

  • Capacity:80-2000 t/h
  • Feeding Size:≤1300 mm

CI Series Impact Crusher

Raw Materials Processing --- Stones with medium hardness and low abrasion such as river pebbles, granite, basalt, limestone, quartz, etc. in quarry and gravel, cement, concrete and asphalt recycling, slag recycling and other industries.

Are you interested in our machines?

Contact Us

Brief Introduction

CI series of new type impact crusher integrates the current domestic and international advanced impact crusher technology, the rotor and crushing cavity are refined design for different applications, and a large number of new high wear-resistant materials are used, which are greatly improved the performance and processing capacity of the equipment . It exhibits excellent crushing effect in applications of industries such as medium hardness and low abrasive quarrying and gravel, cement, concrete and asphalt recycling, slag recycling etc.

FTM

Working Principle

The rugged heavy-duty rotor structure of the CI series impact crusher increases equipment throughput and crushing ratio. The high quality welded construction ensures that the machine can withstand the most impact and achieve good crushing results. The CI1213 impact crusher is a hot sale model of the CI series. Its production capacity is 100-280t/h, the power is 200kw, the rotor specification is φ1200*1300mm, and the feed size can meet the 300mm feeding material.

Chat Online

Advantages

Focusing on crushing machinery for more than 40 years, Fote Machinery has provided professional project guidance, equipment production, production line construct, management and operation services for more than one million customers.

Technical Data

Model Maximum Feeding Size (mm) Power (kw) Capacity (t/h) Dimensions(L×W×H)(mm)
CI1110 250 160 60-210 2826×2087×2285
CI1213 300 200 80-280 2903×2530×2411
CI1316 300 250 100-350 3320×2770×2535
CI1321 300 315 130-430 2955×3285×2585
CI1521 350 2×(200-250) 200-600 3450×3620×2770
Cl1524 350 2×315 240-700 3450×3925×2855
Cl1630 400 710-800 300-900 3693×4520×3173



Model Maximum Feeding Size (mm) Power (kw) Capacity (t/h) Dimensions(L×W×H)(mm)
CI1313 600 200 100-480 2972×2560×2937
CI1415 600 250 120-600 2985×2790×3068
CI1620 800 2×(200-250) 220-900 4261×3480×3780
CI2023 800 2×500 400-2000 5151×4424×4712
Model Maximum Feeding Size (mm) Capacity(t/h)
CI1110 250 60-210
CI1213 300 80-280
CI1316 300 100-350
CI1321 300 130-430
CI1521 350 200-600
Cl1524 350 240-700
Cl1630 400 300-900



Model Maximum Feeding Size (mm) Capacity(t/h)
CI1313 600 100-480
CI1415 600 120-600
CI1620 800 220-900
CI2023 800 200-2000

Note:processing Capacity May Vary With Different Materials And Feeding Sizes.

Cases

Our Crushing Equipment and Dryer Equipment has been exported to over 160 countries, such as, Pakistan, Egypt, Indonesia, Malaysia, Ethiopia, Nigeria, South Africa, etc. The following is how our crushing machines work at the customer site. Furthermore, we provide 100% factory price and maximum discount for you. Additionally, if you are new in this industry, we will provide professional suggestions and solutions for you.
